Model

FS-N9910PLUS-4K

System

Main processor

Industrial-grade embedded microcontroller chip, Huawei HIS chipset Hi3536D

Operating system

Embedded LINUX operating system

System resource

Multi-channel real-time recording synchronously, multi-channel multi-user network operation, USB backup.

Display

Operation interface

WIN style

Display screen

According to the camera display, max. 5.0MP CCTV camera input

1/4/9screen

Video

Image Encode

265/264

Monitor quality

VGA/HDMI

Playback quality

Support 1*5MP/2*3MP/4*2MP

Intelligence analysis

Human detection and capture, Region intrusion, Trip-line detection, human video retrieval

Record and playback

Record mode

All-day/Day/Night/Customization

Video search

Time, date, event, channel search

Video storage

Local HDD, Network

Backup mode

USB

Interface

Video input

10CH  8MP IPC

Video output

1CH VGA,1CH HD MI

Network port

RJ45, 100M

PTZ control

Yes

USB port

2*USB2.0

HDD port

1 SATA(each max support 8TB)

other

Management platform

P2P

Power

12V/2A

Dimension

255mm(L)*233mm(W)*42mm(H)
